Technical document of Y5278 rotary kiln



Technical document of Y5278rotary kiln

Equipment name: Rotary kiln
Usage: Coalmining cement clinker of 6000t/d clinker production line
Specification: Φ5.2〜78m(shell I.D〜length)
Kiln support: 3
Inclination: 4%(sin)
Rotary speed of shell: Main driving: 0.4~4 r/min
                  Auxiliary driving: 0.146 r/min
Motor of main: ZSN4-450-12
             Model of main motor: 800 power
             Armature voltage: 660V
             Rotary speed: 1000 r/min
             Speed regulation range: 100~1000 r/min
Model of tachogenerator: ZYS-3A
             Model of main motor: 22 power
             Voltage: 110V
             Speed regulation range: 0~2000 r/min
Model of main reducer: JH900C-SW305-28
             Center distance: 1980mm
             Speed ratio: 26.646
Model of lubrication oil station: XYZ-160GZ
             Motor of oil pump: 7.5KW(2 units)
             Electric heating period: 24KW/220V
Auxiliary driving device:
             Motor model: Y280M-4
             Power: 90kw
             Voltage: 380V
             Rotary speed: 1480r/min
Model of reducer: ZSY400-35.5-
             Center distance: 880mm
             Speed ratio: 35.795
Electric hydraulic block brake:
             Quantity: 1 set

===========================================================================================================================================

     Jiangsu Pengfei Group Co., Ltd has the great comprehensive ability to provide the best quality services on turn-key basis with the complete equipment、 the installation and the debugging for the new type dry process rotary kiln cement factories under the daily capacity of 8000ton、5000ton and 2500ton and compound fertilizer plants under the annual capacities of the 300000ton. The ^Pengfei ̄ brand rotary kiln cement complete equipment have been sold exported to Russia、The Kingdom of Denmark、Germany、kazakhstan、Mongolia、Ukraine、Uruguay、uzbekistan、 Bangladesh、Pakistan、Laos、Peru、India and so on . MD export project are X18, X519, Son La, Lang Son, Da Ye, Chai Shai Cement factories in Vietnam, Tiger-Head, King Elephant Cement Plants in the union of  MD and so on . All of these cement complete equipment production line have been widely praised by the international friends.
